En-10
Adjusting the Airflow-Direction
Press the AIR FLOW DIRECTION button.
● This control allows you to select a desired airflow direction.
Hold the tip of the
louver and move
gently to right or left.
Right-left louvers
(The louver on the very left in not movable)
In order to heighten the efficiency of cooling and drying modes, the airflow-direc-
tion louvers should be set within the following ranges:
For Cooling: Horizontal, slight downward diagonal.
*For Heating: Double direction, downward diagonal, downward.
Adjusting the Right-Left Direction
Adjust with the right-left louvers.
● Manually adjust the right-left louvers to the desired direction.
Horizontal
Slight downward
diagonal
Downward
Downward
diagonal
Double direction
Types of airflow:
AIR DIRECTION ADJUSTMENT
