2005.08.23
1 Top Panel Sub Assy 9374417018 9374417018 9374417018 9374417018
2 Front Panel-X, Painted 9374094028 9374094028 9374094028 9374094028
3 Fan Guard 9374330010 9374330010 9374330010 9374330010
4 Side Grip 9374173013 9374173013 9374173013 9374173013
5Service Panel Sub Assy 9374415014 9374415014 9374415014 9374415014
6Right Panel Sub Assy 9374416011 9374416011 9374416011 9374416011
7Motor Bracket Sub Assy 9374418015 9374418015 9374418015 9374418015
8 Propeller Fan Assy 9366378013 9366378013 9366378013 9366378013
9 Motor, Induction 9601671060 9601671060 9601671060 9601671060
10 Condenser-A Assy 9374433025 9374433025 9374433018 9374433018
11 Condenser-B Assy 9374434022 9374434022 9374434015 9374434015
12 Separate Wall-X 9374135011 9374135011 9374135011 9374135011
13 Cap Foot 9374345014 9374345014 9374345014 9374345014
14 Base Assy 9374166022 9374166022 9374166022 9374166022
15 3-Way Valve Assy 9372205044 9372205044 9372205044 9372205044
16 3-Way Valve Assy 9372205099 9372205099 9372205099 9372205099
17 Compressor Assy 9374250011 9374250011 9374250011 9374250011
18 Accumulator Assy 9371615011 9371615011 9371615011 9371615011
19 Solenoid --------- --------- 9900165055 9900165055
20 Pressure Switch 9900276010 9900276010 9900186012 9900186012
21 4-Way Valve --------- --------- 9970035012 9970035012
22 Discharge Temperature Thermistor --------- --------- 9900277017 9900277017
23 Check Valve Assy 9374274017 9374274017 9374274017
9374274017
24 Coil (Expansion Valve) --------- --------- 9900190026 9900190026
25 Strainer Assy 9372524015 9372524015 9372524015 9372524015
26 Controller PCB Assy --------- --------- 9705677012 9705677012
27 Magnetic Relay --------- --------- 9900227012 9900227012
28 Terminal-7P 9363276039 9363276039 9363276039 9363276039
29 Expansion Valve --------- --------- 9900170028 9900170028
31 Emblem Rear 9351355005 9372171011 9351355005 9372171011
34 Capacitor (Fan Motor) 9900270049 9900270049 9900270049 9900270049
35 Fuse 0600222529 0600222529 0600222529 0600222529
36 Terminal-2P 9701971015 9701971015 --------- ---------
37 Thermostat (Outdoor) 9900275013 9900275013 --------- ---------
38 Thermostat (Overheat) 9354061002 9354061002 --------- ---------
39 Capillary Assy 9372197332 9372197332 --------- ---------
---- Thermistor Assy --------- --------- 9900274016 9900274016
---- Drain Cap --------- --------- 313166024302 313166024302
---- Drain Pipe --------- --------- 9301102000 9301102000
When you order parts, please make a photocopy of this page and
fill the number of the parts in the "Order" column.
OUTDOOR UNIT
Ref.
No.
Description
AOY54FMAYT AOG54FMAYT
Ord.
Q'ty
Part No.
AOY54UMAYT AOG54UMAYT
AOY54FMAYT
AOG54FMAYT
AOY54UMAYT
AOG54UMAYT
- 25 -
To Next Page
