General AOHR12LGC

27
23
21
24
26
22
25
28
37
31
30
36
38
35
34
33
32
29
OUTDOOR UNIT
AOHR12LGC
17
24 Separate Pipe Assy (Cond) 9317200011
25 Exit Pipe 9317239004
26 Compressor Assy 9315206015
30 3 way Valve Assy 9317174015
-- Insulator B 9317321006
-- Insurator F 9317403009
37 Pulse Motor Valve Assy 9317216005
-- 4 way Valve Assy 9317278010
-- Solenoid 9970055027
-- Condenser Total Assy 9317192019
38 Expansion Valve Coil 9900057039
35 Joint Pipe Assy (Cond) 9317396011
36 Joint Pipe (3 way Valve) 9317214001
33 Discharge Pipe Assy 9317279000
34 Suction Pipe Assy 9317282017
31 Muffler 9317398008
32 4 way Valve 9900162016
27 Cushion 9306410001
28 2 way Valve Assy 9317171014
29 Joint Pipe (2 way Valve) 9317344005
-- Insurator H 9317322003
21 Base Assy 9316980006
22 Condenser Assy 9317193016
23 Entrance Pipe Assy (Cond) 9317194013
Ref. Description Part number
2008.01.31
