General AUG12FBAB User Manual

4
2004.06.07
MODELS
AUG14FBAB AUG14UBAB
AOG14FSDJ AOG14USDJL
DISCHARGE
kg/cm
2
G
COOLING 31.0 31.0
PRESSURE
HEATING 31.0
SUCTION
kg/cm
2
G
COOLING 9.0 9.0
PRESSURE
HEATING 7.5
DISCHARGE
C
COOLING 75 77
TEMP.
HEATING 77
REFRIG. PIPE LENGTH m 7.5
DISCHARGE
C
COOLING 12
AIR TEMP.
HEATING 46
DB/WB
COOLING 27.0 / 19.0
HEATING
DB/WB
COOLING 35.0 / 24.0
HEATING 7.0 / 6.0
PIPE DIA.
LIQUID
mm
6.35
SIZE
GAS 12.7
CONNECTION METHOD Flare
BETWEEN
HEIGHT
m
Max. 8
PIPE LENGTH Max. 20
REFRIGERANT TYPE
R410A
REFRIGERANT CIRCUIT
CONDITION
PIPING
INDOOR
ENTERING
AIR TEMP.
OUTDOOR
ENTERING
AIR TEMP.
–––––
–––––
–––––
–––––
20.0 /
––
C
C
INDOOR UNIT
HI-SPEED
(dB)
(dB)
42
MED-SPEED
(dB)
39
LO-SPEED
(dB)
36
49
OUTDOOR UNIT
NOISE LEVEL
COOL 42 / HEAT 43
COOL 39 / HEAT 40
COOL 36 / HEAT 37
COOL 49 / HEAT 50
Note : Noise was measured in accordance with JIS standards, Japan.
PIPE LENGTH 7.5 m 10 m 15 m 20 m
Additional
refrigerant
900g
10 g / m
1,000g
925g
1,025g
975g
1,075g
1,025g
1,125g
FULL CHARGE
AMOUNT
AUG14FBAB
AUG14UBAB
REFRIGERANT CHARGE ( R410A )
