Product Specifications
Physical
Dimension(L × W × H): 400 × 380 × 540mm
Weight: 26kg
AC supply
AC input: Certified power cord with plug or without plug
Voltage: 220V, 230, 240V 50/60Hz: 100V,120V 50/60Hz
Fuse: AC 230V: 7A/250V AC 100V~120V:15A/250V
Power Consumption: 800W
Control and programming
Signal pinout: pin 1 shield, pin 2 (-), pin 3 (+)
Setting and addressing: LED control panel
Protocol: USITT DMX-512
Pan/tilt resolution: 8 or 16 bit
DMX channels: 14-16
Signal input: 3-pin XLR male
Signal output: 3-pin XLR female
Source
Lamp: 575W discharge
Base: SFC10-4
Approved models: Philips MSI-575/HR (1000 hr; 6000K)
Philips MSI-575/2 (1000 hr; 6500K)
Control: Automatic and DMX remote on/off
Electromechanical effects
Color wheel 1: 11 dichroic colors+white
Color wheel 2: 11 dichroic colors+white
Fixed gobo wheel: 9 replaceable gobos+white
Rotating gobo wheel: 6 replaceable gobos+white
Gobo rotation: adjustable speed and position direction
Dimmer: 0-100% linear dimmer
Strobe: 1-7Hz fast flashing
Rotating 3-facet prism: in/out variable speed and direction
Focus: 2m-infinity
Iris: Mini 4 -Max 15° °
Pan: 0 ~570° °
Tilt: 0 ~270° °
Wheel control: auto-electronic reset
Gobos
Metal gobo: Diameter:31 mm
Maximum image diameter:25 mm
Metal type:white iron
Glass gobo: Diameter:31 mm
Maximum image diameter:25 mm
Glass type:heat-resistant and intensify glass
Glass coating:dichroic
