Section 4 • Repair ProceduresJanuary 2012
Part No. 228901 GS-30 • GS-32 • GS-46 • GS-47 4 - 39
Index Schematic
No. Description Item Function Torque
1 Hand pump ....................................... L ............... Manual brake release .............................. 30 ft-lbs / 41 Nm
2 Needle valve ..................................... M ............... Manual brake release enable .............. 45-50 in-lbs / 5 Nm
8-1
Brake Release Hand Pump Components
The brake release hand pump manifold is mounted behind the entry ladder.
Brake Release Hand Pump Components
