Section 3 • Scheduled Maintenance Procedures January 2012
3 - 34 GS-30 • GS-32 • GS-46 • GS-47 Part No. 228901
CHECKLIST D PROCEDURES
D-2
Replace the Hydraulic Tank
Return Filter Element
Genie requires that this procedure be performed
every 1000 hours or annually, whichever comes
first.
Replacement of the hydraulic tank return filter is
essential for good machine performance and
service life. A dirty or clogged filter may cause the
machine to perform poorly and continued use may
cause component damage. Extremely dirty
conditions may require that the filter be replaced
more often.
Beware of hot oil. Contact with
hot oil may cause severe burns.
Note: The hydraulic tank return filter is mounted on
the function manifold next to the hydraulic power
unit.
1 Clean the area around the oil filter. Remove the
filter with an oil filter wrench.
2 Apply a thin layer of oil to the new oil filter
gasket.
3 Install the new filter and tighten it securely by
hand.
4 Use a permanent ink marker to write the date
and number of hours from the hour meter onto
the filter.
5 Turn the key switch to ground control and pull
out the red Emergency Stop button to the on
position at both the ground and platform
controls.
6 Activate and hold the platform up toggle switch.
7 Inspect the filter and related components to
be sure that there are no leaks.
8 Clean up any oil that may have spilled.
Torque specifications
Hydraulic tank drain plug, dry 40 in-lbs
4.5 Nm
Hydraulic tank drain plug, lubricated 30 in-lbs
3.4 Nm
