Genie S-45 TRAX Service And Repair Manual

Service and Repair Manual July 2019
Specifications
10 S-40 XC • S-45 XC • S-40 TraX • S-45 TraX Part No. 1286829GT
Perkins 404F-E22T Engine
Displacement
134 cu in
2.2 liters
Number of cylinders
4
Bore and Stroke
3.31 x 3.94 inches
84 x 100 mm
Horsepower
48 @ 2800 rpm
38 kW @ 2500 rpm
Firing order
1 - 3 - 4 -
2
Low idle
1500 rpm
313 Hz
High idle
2500 rpm
441.7 Hz
Compression ratio
18:1
Compression pressure
426 psi
29.4 bar
Pressure (psi) of lowest cylinder must be within 50 psi /
3.45 bar of highest cylinder
Governor
electronic
Valve Clearance, cold
Intake
0.008 in
0.2 mm
Exhaust
0.008 in
0.2 mm
Lubrication system
Oil
pressure (@ 2000 rpm)
40 to 60 psi
1.4 to 3 bar
Oil capacity
(including filter)
9.4 -
11.2 quarts
8.9 -
10.6 liters
Oil viscosity requirements
Below 86°F / 30°C
5W-
20
-
4°F to 104°F / -20°C to 40°C 10W-
30
Above 14°F /
-10°C 15W-
40
Unit ships with
15W-40. Extreme operating
temperatures may require the use of alternative engine
oils. For oil requirements, refer to the Engine Operator
Manual for your engine.
Oil pressure sending unit
Oil pressure switch point
14.2 psi
1 bar
Fuel injection system
Injection pump make
Zexel
Injection pressure
2133 psi
147 bar
Fuel requirement
For fuel requirements, refer to the engine Operator
Manual for your engine.
Alternator output
85A @ 12V DC
Fan belt deflection
3/8 in
10 mm
Starter motor
Current
draw, no load 140A -
200A
Brush length, new
0.7480 in
19 mm
Brush length, minimum
0.5 in
12.7 mm
