Genie S-45 TRAX Service And Repair Manual

July 2019 Service and Repair Manual
Manifolds
Part No. 1286829GT S-40 XC • S-45 XC • S-40 TraX • S-45 TraX 63
Function Manifold Components, continued
Index
No.
Description
Schematic
Item
Function
Torque
19
Relief valve 1950 psi / 134 bar
Q
Limit boom extend pressure
20-25 ft-lbs / 27-
34
Nm
20
Flow control valve
N
Compensate for pressure
variation
33
-37 ft-lbs / 45-
50 Nm
21
Differential sensing valve
U
Compensate for pressure
variation
30-35 ft-lbs / 41-
47
Nm
22
Sequence valve
S
Redundant pressure limit for
oscillate circuit
50
-55 ft-lbs / 68-
75 Nm
23
Solenoid Valve. spool type
Y
Primary boom up/down selector
26
-30 ft-lbs / 35-
40 Nm
24
Solenoid Valve. NO, poppet
P
Boom extend selector
33-37 ft-lbs / 45-
50
Nm
25
Solenoid Valve, spool type
V
Turntable rotate left/right selector
26-30 ft-lbs / 35-
40
Nm
26
Check valve
H
Back flow preventer
8-10 ft-lbs / 10-
15 Nm
27
Solenoid Valve, spool type
K
Steer left/right selector
26-30 ft-lbs / 35-
40
Nm
28
Orifice Plug, 0.6mm
I
Brake set delay
5-7 ft-lbs / 7-
9.5 Nm
29
Solenoid Valve, 2 position 3 way
D
Motor displacement control
26-30 ft-lbs / 35-
40
Nm
