Genie Z Series User Manual

April 2018 Maintenance Manual
Programmed Maintenance Procedures
Part No. 1268489GT S
®
Booms • Z
®
Booms 151
P2-5
Check the Boom Wear Pads
Genie requires that this procedure be performed
every 2000 hours.
Maintaining the boom wear pads in good condition
is essential to safe machine operation. Wear pads
are placed on boom tube surfaces to provide a low
friction, replaceable wear pad between moving
parts. Improperly shimmed wear pads or continued
use of extremely worn wear pads may result in
component damage and unsafe operating
conditions.
1 Measure each wear pad. Replace the wear
pad once it reaches the minimum allowable
thickness. If the wear pad is still within
specification, shim as necessary to obtain
minimum clearance with zero binding.
2 Extend and retract the boom through the
entire range of motion to check for tight spots
that may cause binding or scraping of the
boom.
Note: Always maintain squareness between the
outer and inner boom tubes.
SX-150 / SX-180
3 Grease the platform end bottom wear pads
with a suitable lubricant.
SX-150: Grease the #1 and #2 boom tubes.
SX-180: Grease the #0 and #1 boom tubes.
S-40 / S-45 / S-60 / S-65
Wear pad specifications
Minimum
Top and side wear pads
(platform end of boom)
0.50 inch
12.7 mm
Bottom wear pads
(platform end of boom)
0.625 inch
15.9 mm
Top and side wear pads
(pivot
end of boom)
0.50 inch
12.7 mm
Bottom wear pads
(pivot end of boom)
0.625 inch
15.9 mm
S-80 / S-85 / S-80X / S-80XC / S-85XC
Boom wear pad specifications
Boom number one
Minimum
Bottom wear pads
(extension end of boom)
0.50 inch
12.7 mm
Top and side
wear pads
(extension end of boom)
0.625 inch
15.9 mm
Boom number two
Top, bottom and side wear pads
(extension end of boom)
0.50 inch
12.7 mm
Bottom wear pads
(pivot end of boom)
0.50 inch
12.7 mm
Top and side wear pads
(pivot end of boom)
0.625 inch
15.9 mm
Boom number three
Top, bottom and side wear pads
(pivot end of boom)
0.50 inch
12.7 mm
S-100 / S-105 / S-120 / S-125
S-100HD / S-120HD
Boom wear pad specifications
0.50 inch
12.7 mm

Genie Z Series Specifications

General

Lift Capacity	500 lb (227 kg) to 660 lb (300 kg)
Gradeability	30%
Power Source	Diesel, Electric
Capacity	500 lb (227 kg) to 1, 000 lb (454 kg)
Drive System	4-wheel drive
Tire Type	Solid
Steering	2-wheel or 4-wheel
