Genie Z Series User Manual

Scheduled - Annual
April 2018
Maintenance Inspection Report - booms
Part No. 1268489GT S
®
Booms • Z
®
Booms Maintenance Manual 35
Model
Hour meter Date
Serial number Inspector company Machine owner
Inspected by (print) Inspector signature
Inspection Type
A = annual inspections
Legend
Y = yes, acceptable N = no, remove from service Make copies of this report to use for each inspection.
Select the appropriate procedures for the type of
inspection(s) to perform.
R = repaired
∅ = not applicable
If any inspection receives an "N," tag and remove the machine from service, repair and re-inspect it. After repair, place a "R" in the box.
Confirm all applicable quarterly maintenance procedures
have been included and completed with the annual
inspection.
Drive Chassis

Extendable Axle Wear Pads (if equipped) A-4
Check Drive Hub Oil Level and Fastener Torque A-14
Turntable Mechanicals and Hydraulics
Grease the Turntable Rotation Bearing A-1
Check Turntable Bearing Bolts A-2
Inspect for Turntable Bearing Wear A-3
Boom(s) and Platform
Jib Rotate Bearing (if equipped) A-5
Grease the Platform Overload Mechanism A-7
Test Platform Overload - All Models, Except ALC1000 and
S-60HC Models
A-8
Test Platform Overload - (ALC1000 models) A-9
Test Platform Overload - (S-60 HC models) A-10
Test Dual Capacity / Overload - SX-105XC, SX-125XC,
SX-135 XC
A-15
Test Dual Capacity / Overload - Z-45XC A-16
Test Dual Capacity / Overload - S80XC, S-85XC A-17
Inspect Boom Cables - All S-60, S-80 Models A-11
Inspect Boom Cables - S-100 to S-125, S-100HD,
S-120HD, SX105XC, SX-125XC
A-12
Inspect Boom Cables - SX-135XC, SX-150, SX-180 A-13
Functions and Controls
Test the Bypass/Recovery Key Switch A-6

Genie Z Series Specifications

General

Lift Capacity	500 lb (227 kg) to 660 lb (300 kg)
Gradeability	30%
Power Source	Diesel, Electric
Capacity	500 lb (227 kg) to 1, 000 lb (454 kg)
Drive System	4-wheel drive
Tire Type	Solid
Steering	2-wheel or 4-wheel
