Genie Z Series User Manual

Maintenance Manual April 2018
Quarterly Maintenance Procedures
56 S
®
Booms • Z
®
Booms Part No. 1268489GT
Q-14
Test the Emergency Power
System
(excludes ALC-600 and ALC-1000
Models)
Genie specifications require that this procedure be
performed quarterly.
Testing the emergency power system regularly is
essential to safe machine operation if the primary
power source fails.
1 Turn the key switch to ground control and pull
out the red Emergency Stop button to the on
position at both the ground and platform
controls.
2 At the ground controls, break the security tie
and lift the emergency power switch cover (if
equipped).
3 Simultaneously hold the emergency power
switch on and operate each boom function
through a partial cycle.
Result: All boom functions operate.
4 Close the emergency power switch cover and
secure the cover with a security tie (if
equipped).
5 Turn the key switch to platform controls.
6 At the platform controls, break the security tie
and lift the emergency power switch cover (if
equipped).
7 Press down on the foot switch and
simultaneously hold the emergency power
switch on and operate each boom function
through a partial cycle.
Result: All boom functions operate.
8 Close the emergency power switch cover and
secure the cover with a security tie (if
equipped).
Q-15
Test the Engine Idle Select
Operation - Engine Models
Genie specifications require that this procedure be
performed quarterly.
A properly operating engine idle select function is
essential to good engine performance and safe
machine operation. There are two settings.
Low idle (turtle symbol) allows the operator to
control individual boom functions. Drive functions
will operate at low idle on most models, but at
reduced performance.
High idle (rabbit symbol) should be used for
normal machine operation.
S-80 XC, S-85 XC, S-100, S-105, S-120, S-125,
S-100HD, S-120HD, SX-105 XC, SX-125 XC,
SX-135 XC, SX-150, SX-180, Z-80/60, Z-135/70
and ZX-135/70 Models:
1 Turn the key switch to ground controls.
2 Pull out the red Emergency Stop button to the
on position at both the ground and platform
controls.
3 Start the engine from the ground controls.
4 Push and release the rpm select button until
high rpm is selected (rabbit symbol).
Result: The engine should change to high idle.

Genie Z Series Specifications

General

Lift Capacity	500 lb (227 kg) to 660 lb (300 kg)
Gradeability	30%
Power Source	Diesel, Electric
Capacity	500 lb (227 kg) to 1, 000 lb (454 kg)
Drive System	4-wheel drive
Tire Type	Solid
Steering	2-wheel or 4-wheel
