Zoom | 118Applications

Reference Arc -

Measure to start

point

Next step

After defining the reference arc the REFERENCE ARC screen will appear.

REFERENCE ARC

Next step

Select a softkey option, MEAS or SET OUT, to proceed a subapplication.

Field Description

Start Pt Point ID of the start point.

C-Pt Point ID of the center point.

End Pt Point ID of the end point.

Radius Radius of the arc.

New

To define a new base arc.

MEAS

To measure Line & Offset.

SET OUT

To set out.
