CONNECTIONS
Power supply
The GEONAV can be powered by
using the built-in battery pack, the
appropriate electric network adapter,
the lighter plug adapter with speaker
or the lighter plug adapter.
Insert the unit into its cradle, in-
stall the power supply cable with the
jack connector into the cradle plug as shown in the figure,
then exert light pressure until clicking. When the cable is
disconnected, make sure that the connector is protected by
the appropriate rubber cap.
NOTE: The jack connection is splashproof. Should seawater seep into the connector,
with the unit off, disconnect the jack, wash it with fresh water, then let it dry.
External power supply
To power the unit through the house electric network (100÷240
VAC), use the appropriate electric network adapter.
To power the unit through the car lighter plug (12/24 VDC),
use the appropriate car lighter adapter or the lighter plug
adapter with speaker.
NOTE: Do not cut the network adapter or battery charger speaker to connect directly
the unit to the external power supply. Do not use any bypass circuit. Use only the
network adapter or battery charger speaker supplied together with the cradle. Any
damage caused by the use of non-original or modified components is excluded from
the warranty.
Battery pack
The rechargeable battery pack allows using the GEONAV as a
portable unit. The unit can be powered by the batteries only or
connected to an external power supply.
