GeoVision GV-CS1320 User Manual

110
[Input Ports Function]
 Door / Car Sensor: When the door is forcibly opened, Door Sensor will trigger
Forced Open. If Forced Open is selected on GV-ASManager, GV-CS1320 will send
forth alarm sound.
 Door / Gate Button: When Door / Gate Button gets triggered, the door will be
opened.
 Fire Sensor: When the flame detector senses fire, Fire Sensor will be triggered. If
Fire Alarm is selected on GV-ASManager, GV-CS1320 will send forth alarm sound.
 Tamper Sensor: When GV-CS1320 is being physically tampered with, the alarm
events will show on GV-ASManager. If Tamper is selected on GV-ASManager, GV-
CS1320 will send forth alarm sound.
Note: For the alarm sound to be sent by GV-CS1320, the corresponding settings must
be specified on GV-ASManager first.
[Output Ports Function]
 Electric Lock: The lock output is triggered when the correct card is presented to open
the locking device.
 Event Alarm: The alarm output is triggered when the defined alarm events occur.
Inputs Alarm Events
Door Sensor Forced Open
Fire Sensor Fire Alarm
Tamper Sensor Tamper
 Door Bell: The door bell is triggered upon activating the touch pad.
3. Click Apply. The green light represents the active connection between GV-CS1320 and
GV-I/O Box whereas a red light indicates otherwise.

GeoVision GV-CS1320 Specifications

General

Type	IP security camera
Certification	CE, FCC, RCM, RoHS
Day/night mode	Yes
Languages support	CHI (TR), ENG, ESP, FRE, POR, RUS
Number of languages	6
Operating frequency	13.56 MHz
Placement supported	Outdoor
Connectivity technology	Wired
Sensor type	CMOS
Number of sensors	1
Optical sensor size	1/2.8 \
Number of effective pixels (H x V)	1920 x 1080 pixels
White balance	Auto, Manual
Camera pan control	No
Camera shutter type	Electronic
Camera shutter speed	1/5 s
Minimum illumination	0.02 lx
Adjustment shutter speed	Auto/Manual
Field of view (FOV) angle	180 °
Audio formats supported	AAC, G.711
Signal-to-Noise Ratio (SNR)	52 dB
LED type	IR
Night vision distance	3 m
Number of illumination LEDs	2
Fixed focal length	1.7 mm
Focal length range	1 - 1 mm
Maximum aperture number	2.5
Total megapixels	2 MP
Video formats supported	H.264, M-JPEG
Wi-Fi	-
Ethernet interface type	Fast Ethernet
Supported network protocols	HTTP, HTTPS, TCP, UDP, SMTP, FTP, DHCP, NTP, UPnP, DynDNS, 3GPP/ISMARTSP, PSIA, SNMP, QoS(DSCP), ONVIF(ProfileS)and(ProfileC)
Compatible memory cards	MicroSD (TransFlash)
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
DC output current	2.5 A
DC output voltage	12
Power source type	DC, PoE
Power consumption (max)	25.5 W
Sustainability certificates	RoHS
Mounting type	Wall
Product color	Black
International Protection (IP) code	IP66
Memory card included	MicroSD
Included memory card size	2 GB

Weight and Dimensions

Depth	34.5 mm
Width	80 mm
Height	137 mm
Weight	315 g
