Need help?Do you have a question about the GeoVision GV-CS1320 and is the answer not in the manual?
General| Type | IP security camera |
|---|---|
| Certification | CE, FCC, RCM, RoHS |
| Day/night mode | Yes |
| Languages support | CHI (TR), ENG, ESP, FRE, POR, RUS |
| Number of languages | 6 |
| Operating frequency | 13.56 MHz |
| Placement supported | Outdoor |
| Connectivity technology | Wired |
| Sensor type | CMOS |
| Number of sensors | 1 |
| Optical sensor size | 1/2.8 \ |
| Number of effective pixels (H x V) | 1920 x 1080 pixels |
| White balance | Auto, Manual |
| Camera pan control | No |
| Camera shutter type | Electronic |
| Camera shutter speed | 1/5 s |
| Minimum illumination | 0.02 lx |
| Adjustment shutter speed | Auto/Manual |
| Field of view (FOV) angle | 180 ° |
| Audio formats supported | AAC, G.711 |
| Signal-to-Noise Ratio (SNR) | 52 dB |
| LED type | IR |
| Night vision distance | 3 m |
| Number of illumination LEDs | 2 |
| Fixed focal length | 1.7 mm |
| Focal length range | 1 - 1 mm |
| Maximum aperture number | 2.5 |
| Total megapixels | 2 MP |
| Video formats supported | H.264, M-JPEG |
| Wi-Fi | - |
| Ethernet interface type | Fast Ethernet |
| Supported network protocols | HTTP, HTTPS, TCP, UDP, SMTP, FTP, DHCP, NTP, UPnP, DynDNS, 3GPP/ISMARTSP, PSIA, SNMP, QoS(DSCP), ONVIF(ProfileS)and(ProfileC) |
| Compatible memory cards | MicroSD (TransFlash) |
| Operating temperature (T-T) | -20 - 50 °C |
| Operating relative humidity (H-H) | 10 - 90 % |
| DC output current | 2.5 A |
| DC output voltage | 12 |
| Power source type | DC, PoE |
| Power consumption (max) | 25.5 W |
| Sustainability certificates | RoHS |
| Mounting type | Wall |
| Product color | Black |
| International Protection (IP) code | IP66 |
| Memory card included | MicroSD |
| Included memory card size | 2 GB |
Weight and Dimensions| Depth | 34.5 mm |
|---|---|
| Width | 80 mm |
| Height | 137 mm |
| Weight | 315 g |
