P.6
P. 5P. 5
22 4 3455 6
7
7
1
22 4 345 56
1
7 7
TYP-716
TYP-717
產品結構 Product Structure
操作面版 Control Panel
1.操作面版Control Panel
2.易拆式旋鈕(一對)Bottom Cover Knob (1 pair)
3.底蓋Bottom Cover
4.油杯(一對)Oil Container (1 pair)
5.風網(一對)Fan Grille (1 pair)
6.照明燈Lighting
7.防漏油碟(一對)Oil Collector (1 pair)
8.速度調校掣(左)Left Speed Control
9.速度調校掣(右)Right Speed Control
10.總開關Main Power Switch
11.照明燈開關Light Switch
高速Super 低速Normal
高速Super 低速Normal
8 9 10 11
