GET BOOST - Page 5

5
EN
4. Disconnect the original
first injector connector.
Connect the male B1
connector of the GET wiring
to the original first injector
connector.
Connect the female B2
connector of the GET wiring to
the original first injector.
5. Disconnect the original
male and female connectors
of the throttle body.
Connect the male C1
connector of the GET wiring
to the original female
throttle body connector.
Connect the female C2
connector of the GET wiring
to the original male throttle
body connector.
B1
C1
B2
C2
OEM
First injector
OEM
Throttle Body
OEM
Throttle Body
OEM
First injector
