GET SX1 PRO 2T - Page 10

10EN
1. Remove the protection
caps and connect
the RESET TPS cable
(included in the package)
to the “MAIN” connector
of the SX1 PRO 2T control
unit. As an alternative
to the RESET TPS cable,
you can use the original
Wake-up connector
supplied with the
motorcycle by connecting
it to the diagnosis socket.
2. Connect a fully
charged 12V battery to
the “RESET TPS” cable:
first the red wire to the
positive (+) pole and then
the black wire to the
negative (-) pole.
2 1
3. Rotate the throttle
fully to the open
position and wait at
least 5 seconds. The
final positions of the
exhaust valve are
analyzed and saved -
the operation is clearly
audible. Wait until
you no longer feel any
adjustment movement
coming from the motor.
5 sec.
