EMD / EMD-F / EMD-F-IS / EMD-F/R / EMD Invers
9
Safety sensor, open and close
4 Safety sensor, open and close
X
In the case of 2-leaf systems connect the safety sensors of the active leaf with the active leaf control unit and
those of the xed leaf with the xed leaf control unit.
X
Install the sensor for monitoring closing on the door leaf, opposite hinge side.
If the SIS is activated during closing, the door reverses and opens again.
X
Install the sensor for monitoring opening on the door leaf, hinge side.
If the SIO is activated during opening, the door stops.
On detection the sensor output is open (GND applied to SIS or SIO input).
X
Check function and correct setting of the sensors during commissioning and when servicing the assembly.
The behaviour of the door when the SIS and SIO safety sensors are triggered can be set in the service menu.
If a wall or similar object is located in the door's open position, the SIO's wall blanking range is automatically set
during the teaching process. The range can be changed via the service menu, where necessary.
In the case of 2-leaf drives, the active and xed leaves stop when opening if one of the SIO safety sensors is trig-
gered. If parameter
f3
“SI3 - terminal SIS, "SI3 function" is set to
06
"SIO SF-GF", the wall blanking is not consid-
ered.
To correct the wall blanking range
X
Set parameter
aB
, "SI3 - terminal SIS, "SI3 wall blanking range" to the desired value
(1%…99% of the maximum opening angle, 0=no wall blanking)
4.1 Safety sensor strip pair GC 338
X
Follow installation instructions GC 338.
The connector plug of the GC 338 has 6 poles. Terminal 6 is not occupied.
X
Set DIP switch 3 (TST/SBY) on the GC 338 interface module to ON (factory setting).
X
Set the testing parameter:
à DPS: Set
Te
to
01
(testing with 24 V).
à ST220: Set "Output signals", “Test SI", "Test SI" to "Testing with 24 V".
