GHM GREISINGER G 1114 User Manual

G
1
1
1
4
S
a
f
e
t
y
|
2
B
-
H
8
8
.
0
.
1
2
.
D
B
2
-
1
.
1
7
/
2
9
2.4 Intended use
The G 1114 measures the absolute pressure in the air, clean water or in non-
corrosive/non-ionising gases. A direct measurement of the environmental pressure
can take place or the measurement pressure is taken with a suitable hose connected
to the port. Relative measurements can also be conducted with the integrated special
function .
Applications include:
Barometric measurements (e.g. weather)
Vacuum measurements (up to 0 hPa abs., negative pressure via hose or even
with complete device evacuation)
Pneumatic measurements (up to 14000 hPa abs. or 14 bar abs.)
The pressure connection is made at the supplied interchangeable pressure connection
ports with suitable hoses - 4 different connection options are available as standard,
many other connection options can be used easily and reliable with G 1/8 adapters.
The device must only be used under the conditions and for the purposes for which it
was designed.
It must be handled with care and used according to the technical data (do not throw,
strike, etc.). Suitable measures must be used to protect the pressure connections and
be protected from dirt.
N
O
T
E
Complete evacuation see .
2.5 Qualified personnel
For commissioning, operation and maintenance, the relevant personnel must have
adequate knowledge of the measuring process and the significance of the measure-
ments. This document makes a valuable contribution to this. The instructions in this
document must be understood, observed and followed.
In order to avoid any risks arising from interpretation of the measurements in the con-
crete application, the user must have additional expertise. The user is solely liable for
damages/danger resulting from misinterpretation due to inadequate expertise.
