34
Brake Brake lever clamp bolt M4
M5&M6
2.4-3.9 Nm
5.8-7.8 Nm
Brake lever clamp bolt for carbon fiber
handlebar
3.9-4.9 Nm
Cable clamp bolt M5 2.9-6.8 Nm
Pad fixing bolt M5 for caliper brake 7.8-9.8 Nm
Pad fixing bolts M6 for V-Brake 5.8-7.8 Nm
!
!
!
!
Water bottle cage M5 2.9-4.9 Nm
Pedals 36.2-41.1 Nm
Pad fixing bolt
Cable clamp bolt
Lever clamp bolt
Lever clamp bolt
Cable clamp bolt
Pad fixing bolt
Caliper brake
V-Brake
