Gigabyte B550 AORUS ELITE V2

Internal
Connectors
 1 x 24-pin ATX main power connector
 1 x 8-pin ATX 12V power connector
 2 x M.2 Socket 3 connectors
 4 x SATA 6Gb/s connectors
 1 x CPU fan header
 1 x water cooling CPU fan header
 3 x system fan headers
 1 x CPU cooler LED strip/RGB LED strip header
 2 x addressable LED strip headers
 2 x RGB LED strip headers
 1 x front panel header
 1 x front panel audio header
 1 x USB Type-C
®
header, with USB 3.2 Gen 1 support
 1 x USB 3.2 Gen 1 header
 2 x USB 2.0/1.1 headers
 1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S
module only)
 1 x Clear CMOS jumper
Back Panel
Connectors
 1 x DisplayPort
 1 x HDMI port
 2 x SMA antenna connectors (2T2R)jk
 2 x USB 3.2 Gen 2 Type-A
(Note)
/USB 3.2 Gen 1 ports (red)
 3 x USB 3.2 Gen 1 ports
 2 x USB 2.0/1.1 ports
 1 x Q-Flash Plus button
 1 x RJ-45 port
 1 x optical S/PDIF Out connector
 5 x audio jacks
I/O Controller  iTE
®
I/O Controller Chip
Hardware
Monitor
 Voltage detection
 Temperature detection
 Fan speed detection
 Water cooling ow rate detection
 Overheating warning
 Fan fail warning
 Fan speed control
* Whether the fan speed control function is supported will depend on the fan you install.
BIOS  1 x 128 Mbit ash
 Use of licensed AMI UEFI BIOS
 PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
- 9 -
(Note) For AMD Ryzen
™
5000 Series/3000 Series Processors only.
j Only for B550 AORUS ELITE AX V2.
k Only for B550 AORUS ELITE AX V3.
