Storage Interface  1 x M.2 connector (Socket 3, M key, type 22110/2280/2260/2242 PCIe x4/x2
SSD support)
 4 x SATA 6Gb/s connectors
 Support for RAID 0, RAID 1, RAID 5, and RAID 10
USB  Chipset:
- 5 x USB 3.2 Gen 1 ports (3 ports on the back panel, 2 ports available through
the internal USB header)
- 6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through
the internal USB headers)
Internal
Connectors
 1 x 24-pin ATX main power connector
 1 x 8-pin ATX 12V power connector
 1 x CPU fan header
 1 x system fan header
 1 x addressable LED strip header
 1 x RGB LED strip header
 1 x M.2 Socket 3 connector
 4 x SATA 6Gb/s connectors
 1 x front panel header
 1 x front panel audio header
 1 x USB 3.2 Gen 1 header
 2 x USB 2.0/1.1 headers
 2 x Thunderbolt
™
add-in card connectors
 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0/
GC-TPM2.0 SPI V2 module only)
 1 x serial port header
 1 x Clear CMOS jumper
 1 x Q-Flash Plus button
Back Panel
Connectors
 1 x PS/2 keyboard/mouse port
 1 x D-Sub port
 1 x DVI-D port
 1 x HDMI port
 3 x USB 3.2 Gen 1 ports
 2 x USB 2.0/1.1 ports
 1 x RJ-45 port
 3 x audio jacks
I/O Controller  iTE
®
I/O Controller Chip
Hardware
Monitor
 Voltage detection
 Temperature detection
 Fan speed detection
 Overheating warning
 Fan fail warning
 Fan speed control
* Whether the fan speed control function is supported will depend on the fan you install.
- 7 -

Gigabyte B560M DS3H V3 Specifications

General

Processor socket	LGA 1200 (Socket H5)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Core i3, Intel Core i5, Intel Core i7, Intel Core i9, Intel Pentium
Maximum number of SMP processors	1
Maximum internal memory supported by processor	128 GB
ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR4-SDRAM
Supported memory clock speeds	2133, 2400, 2666, 2933, 3000, 3200 MHz
Supported memory clock speed (max)	3200 MHz
Wi-Fi	No
LAN controller	Intel I219V
Ethernet interface type	Gigabit Ethernet
USB 2.0 connectors	2
USB 3.2 Gen 2 (3.1 Gen 2) connectors	0
USB connector type	USB Type-A
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
RAID levels	0, 1, 5, 10
Supported storage drive types	HDD & SSD
Number of storage drives supported	5
Supported storage drive interfaces	M.2, SATA III
BIOS type	UEFI AMI
ACPI version	5.0
BIOS memory size	256 Mbit
Desktop Management Interface (DMI) version	2.7
Maximum resolution	4096 x 2160 pixels
Parallel processing technology support	2-Way CrossFireX
Audio chip	Realtek ALC897
Component for	PC
Product color	Brown
Motherboard chipset	Intel H470 Express
PC health monitoring	FAN, Temperature, Voltage
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Windows operating systems supported	Windows 10 x64, Windows 11 x64
Country of origin	China
Quantity per shipping (inner) case	1 pc(s)
Battery type	CR2032
Battery weight	3 g
Battery technology	Lithium-Manganese Dioxide (LiMnO2)
Cables included	SATA
Bundled software	Norton® Internet Security (OEM version) LAN bandwidth management software
Package width	265 mm
Package height	54 mm
Package weight	870 g
Warranty period	3 year(s)

Weight and Dimensions

Width	244 mm
Height	35 mm
