Gigabyte B650E AORUS ELITE X AX ICE User Manual

- 8 -
Storage Interface  1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3,
M key, type 25110/2580 SSDs:
 AMD Ryzen
™
7000 Series Processors support PCIe 5.0 x4/x2 SSDs
 AMD Ryzen™ 8000 Series -Phoenix 1/Phoenix 2 Processors support PCIe
4.0 x4/x2 SSDs
 1 x M.2 connector (M2B_CPU), integrated in the CPU, supporting Socket 3,
M key, type 22110/2280 SSDs:
 AMD Ryzen
™
7000 Series Processors support PCIe 4.0 x4/x2 SSDs
 AMD Ryzen
™
8000 Series -Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs
 AMD Ryzen
™
8000 Series -Phoenix 2 Processors support PCIe 4.0 x2 SSDs
 1 x M.2 connector (M2C_SB), integrated in the Chipset, supporting Socket 3,
M key, type 22110/2280 PCIe 4.0 x4/x2 SSDs
 4 x SATA 6Gb/s connectors
 RAID 0, RAID 1, and RAID 10 support for NVMe SSD storage devices
 RAID 0, RAID 1, and RAID 10 support for SATA storage devices
USB  CPU:
- 1 x USB Type-C
®
port on the back panel, with USB 3.2 Gen 2 support
(Note)
- 2 x USB 3.2 Gen 2 Type-A ports (red) on the back panel
 CPU + USB 2.0 Hub:
- 4 x USB 2.0/1.1 ports on the back panel
 Chipset:
- 1 x USB Type-C
®
port with USB 3.2 Gen 2x2 support, available through the
internal USB header
- 3 x USB 3.2 Gen 1 ports (1 port on the back panel, 2 ports available through
the internal USB header)
- 4 x USB 2.0/1.1 ports available through the internal USB headers
 Chipset+USB 3.2 Gen 1 Hub:
- 4 x USB 3.2 Gen 1 ports on the back panel
Internal
Connectors
 1 x 24-pin ATX main power connector
 1 x 8-pin ATX 12V power connector
 1 x 4-pin ATX 12V power connector
 1 x CPU fan header
 1 x CPU fan/water cooling pump header
 3 x system fan headers
 1 x system fan/water cooling pump header
 3 x addressable RGB Gen2 LED strip headers
 1 x RGB LED strip header
 3 x M.2 Socket 3 connectors
 4 x SATA 6Gb/s connectors
 1 x front panel header
 1 x front panel audio header
 1 x USB Type-C
®
header, with USB 3.2 Gen 2x2 support
 1 x USB 3.2 Gen 1 header
 2 x USB 2.0/1.1 headers
(Note) This USB Type-C
®
port supports a maximum speed of 40Gbps. Actual support may vary by CPU.

Gigabyte B650E AORUS ELITE X AX ICE Specifications

General

Processor socket	Socket AM5
Processor manufacturer	AMD
Compatible processor series	AMD Ryzen™ 7
Maximum number of SMP processors	1
Maximum internal memory supported by processor	192 GB
ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR5-SDRAM
Supported memory clock speeds	8000, 7800, 7600, 7200, 7000, 6800, 6666, 6600, 6400, 6200, 6000, 5600, 5200, 4800, 4400 MHz
Supported memory clock speed (max)	8000 MHz
Supported memory module capacities	1GB, 2GB, 4GB, 8GB, 12GB, 16GB, 48GB
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Bluetooth version	5.3
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
WLAN controller model	AMD RZ616
Ethernet interface type	2.5 Gigabit Ethernet
USB 2.0 connectors	2
USB 3.2 Gen 2 (3.1 Gen 2) connectors	0
DisplayPort version	1.4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	5
RAID levels	0, 1, 5, 10
Number of HDDs supported	3
Supported storage drive types	HDD & SSD
Number of storage drives supported	7
Supported storage drive interfaces	M.2, SATA III
Cables included	SATA
Bundled software	Norton Internet Security (OEM version) LAN bandwidth management software
BIOS type	UEFI AMI
ACPI version	5.0
BIOS memory size	256 Mbit
Desktop Management Interface (DMI) version	2.7
Maximum resolution	4096 x 2160 pixels
Parallel processing technology support	-
Component for	PC
Product color	White
Motherboard chipset	AMD B650
PC health monitoring	FAN, Temperature, Voltage
Audio output channels	7.1 channels
Motherboard form factor	ATX
Windows operating systems supported	Windows 10 x64, Windows 11 x64
Battery type	CR2032
Battery weight	3 g
Battery technology	Lithium-Manganese Dioxide (LiMnO2)
Country of origin	China
Quantity per shipping (inner) case	1 pc(s)
Warranty period	3 year(s)
Package depth	270 mm
Package width	335 mm
Package height	80 mm
Package weight	2190 g

Weight and Dimensions

Depth	244 mm
Width	305 mm
Height	35 mm
