Page #9 background imageLoading...
Page #9 background image
- 9 -
Storage Interface CPU:
- 2 x M.2 connectors (Socket 3, M key, type 25110/2280 PCIe 4.0 x4/x2 SSD
support)
Chipset:
- 4 x SATA 6Gb/s connectors
RAID 0, RAID 1, and RAID 10 support for NVMe SSD storage devices
RAID 0, RAID 1, and RAID 10 support for SATA storage devices
USB CPU:
- 1 x USB Type-C
®
port on the back panel, with USB 3.2 Gen 2 support
- 1 x USB 3.2 Gen 2 Type-A port (red) on the back panel
CPU + USB 2.0 Hub:
- 4 x USB 2.0/1.1 ports on the back panel
Chipset:
- 1 x USB Type-C
®
port with USB 3.2 Gen 2 support, available through the
internal USB header
- 4 x USB 3.2 Gen 1 ports (2 ports on the back panel, 2 ports available
through the internal USB header)
- 4 x USB 2.0/1.1 ports available through the internal USB headers
Internal
Connectors
1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x CPU fan header
3 x system fan headers
1 x addressable LED strip header
1 x RGB LED strip header
2 x M.2 Socket 3 connectors
4 x SATA 6Gb/s connectors
1 x front panel header
1 x front panel audio header
1 x USB Type-C
®
header, with USB 3.2 Gen 2 support
1 x USB 3.2 Gen 1 header
2 x USB 2.0/1.1 headers
1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI
2.0 module only)
1 x serial port header
1 x reset button
1 x reset jumper
1 x Clear CMOS jumper

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Gigabyte B650M GAMING X AX and is the answer not in the manual?

Gigabyte B650M GAMING X AX Specifications

General IconGeneral
Processor manufacturerAMD
Compatible processor seriesAMD Ryzen 3, AMD Ryzen 5, AMD Ryzen 7, AMD Ryzen 9 7th Gen
Supported processor socketsSocket AM5
Maximum number of SMP processors1
Non-ECCYes
Memory channelsDual-channel
Memory slots typeDIMM
Number of memory slots4
Supported memory typesDDR5-SDRAM
Maximum internal memory192 GB
Supported memory clock speeds4800, 5200, 5600, 6000, 6200, 6400, 6600, 6800, 7000, 7200, 7600, 7800, 8000 MHz
Supported memory clock speed (max)8000 MHz
LAN controllerRealtek RTL8125
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax)
Bluetooth version5.3
Top Wi-Fi standardWi-Fi 6E (802.11ax)
WLAN controller modelRealtek RTL8852CE
Ethernet interface type2.5 Gigabit Ethernet
USB 2.0 connectors2
USB connector typeUSB Type-A, USB Type-C
DisplayPort version1.4
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity0
RAID levels0, 1, 10
Supported storage drive typesHDD & SSD
Number of storage drives supported6
Supported storage drive interfacesM.2, SATA III
Cables includedSATA
Bundled softwareNorton® Internet Security (OEM version) LAN bandwidth management software
BIOS typeUEFI AMI
ACPI version5.0
BIOS memory size256 Mbit
Desktop Management Interface (DMI) version2.7
DirectX version12.0
Maximum resolution4096 x 2160 pixels
Parallel processing technology supportNot supported
Audio chipRealtek ALC897
Component forPC
Product colorBrown
Motherboard chipsetAMD B650
PC health monitoringFAN, Temperature, Voltage
Audio output channels7.1 channels
Motherboard form factormicro ATX
Windows operating systems supportedWindows 10 x64, Windows 11 x64
Package depth268 mm
Package width270 mm
Package height68 mm
Package weight1700 g
Country of originChina
Quantity per shipping (inner) case1 pc(s)
Warranty period3 year(s)
Battery typeCR2032
Battery weight3 g
Battery technologyLithium-Manganese Dioxide (LiMnO2)
Weight and Dimensions IconWeight and Dimensions
Depth244 mm
Height35 mm
