Gigabyte B660 GAMING X AX DDR4 User Manual

- 10 -
Back Panel
Connectors
 1 x USB 3.2 Gen 2 Type-A port (red)
 2 x USB 3.2 Gen 1 ports
 5 x USB 2.0/1.1 ports
 2 x SMA antenna connectors (2T2R)k
 1 x DisplayPort
 1 x HDMI 2.0 port
 1 x RJ-45 port
 6 x audio jacks
I/O Controller  iTE
®
I/O Controller Chip
Hardware
Monitor
 Voltage detection
 Temperature detection
 Fan speed detection
 Water cooling ow rate detection
 Fan fail warning
 Fan speed control
* Whether the fan (pump) speed control function is supported will depend on the fan
(pump) you install.
BIOS  1 x 256 Mbit ash
 Use of licensed AMI UEFI BIOS
 PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Unique Features  Support for APP Center
* Available applications in APP Center may vary by motherboard model. Supported
functions of each application may also vary depending on motherboard specications.
- @BIOS
- EasyTune
- Fast Boot
- Game Boost
- ON/OFF Charge
- RGB Fusion
- Smart Backup
- System Information Viewer
 Support for Q-Flash Plus
 Support for Q-Flash
 Support for Xpress Install
k Only for B660 GAMING X AX DDR4.

Gigabyte B660 GAMING X AX DDR4 Specifications

General

Processor socket	LGA 1700
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Core i3, Intel Core i5, Intel Core i7, Intel Core i9, Intel Pentium
Maximum number of SMP processors	1
Component for	PC
Motherboard chipset	Intel B660
PC health monitoring	CPU, FAN, Temperature, Voltage
Audio output channels	7.1 channels
Motherboard form factor	ATX
Windows operating systems supported	Windows 10 x64, Windows 11 x64
DisplayPort version	1.2
USB 2.0 ports quantity	5
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
Number of M.2 (M) slots	3
Wi-Fi	Yes
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Bluetooth version	5.2
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
WLAN controller model	RZ608
Ethernet interface type	2.5 Gigabit Ethernet
Cables included	SATA
Number of SATA III connectors	4
BIOS type	UEFI AMI
ACPI version	5.0
BIOS memory size	256 Mbit
Desktop Management Interface (DMI) version	2.7
Maximum resolution	4096 x 2160 pixels
Parallel processing technology support	-
RAID levels	0, 1, 5, 10
Supported storage drive types	HDD & SSD
Supported storage drive interfaces	M.2, SATA III
Memory slots type	DIMM
Supported memory types	DDR4-SDRAM
Maximum internal memory	128 GB
Supported memory clock speeds	2133, 2400, 2666, 2933, 3000, 3200, 3300, 3333, 3400, 3466, 3600, 3666, 3733, 3800, 3866, 4000, 4133, 4266, 4300, 4400 MHz
Harmonized System (HS) code	84733020

Weight and Dimensions

Depth	244 mm
Width	305 mm
