Gigabyte B760M D DDR4 User Manual

- 7 -
USB  Chipset:
- 6 x USB 3.2 Gen 1 ports (4 ports on the back panel, 2 ports available
through the internal USB header)
- 6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through
the internal USB headers)
Internal
Connectors
 1 x 24-pin ATX main power connector
 1 x 8-pin ATX 12V power connector
 1 x CPU fan header
 2 x system fan headers
 1 x RGB LED strip header
 2 x M.2 Socket 3 connectors
 4 x SATA 6Gb/s connectors
 1 x front panel header
 1 x front panel audio header
 1 x S/PDIF Out header
 1 x USB 3.2 Gen 1 header
 2 x USB 2.0/1.1 headers
 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI
2.0 module only)
 1 x serial port header
 1 x Clear CMOS jumper
Back Panel
Connectors
 2 x USB 2.0/1.1 ports
 1 x D-Sub portjk
 1 x HDMI port
 4 x USB 3.2 Gen 1 ports
 1 x RJ-45 port
 3 x audio jacks
I/O Controller  iTE
®
I/O Controller Chip
Hardware
Monitor
 Voltage detection
 Temperature detection
 Fan speed detection
 Water cooling ow rate detection
 Fan fail warning
 Fan speed control
* Whether the fan speed control function is supported will depend on the cooler you
install.
j Only for B760M D DDR4.
k Only for B760M H DDR4.

Gigabyte B760M D DDR4 Specifications

General

Form Factor	Micro ATX
Chipset	Intel B760
Memory Type	DDR4
Memory Slots	4
Maximum Memory	128 GB
Socket	LGA 1700
PCIe x16 Slots	1
PCIe x1 Slots	2
SATA Ports	4
M.2 Slots	2
Audio	Realtek ALC897
LAN	Realtek GbE LAN
Video Outputs	1 x DisplayPort 1 x HDMI port
