- 9 -
Internal
Connectors
 1 x 24-pin ATX main power connector
 1 x 8-pin ATX 12V power connector
 1 x 4-pin ATX 12V power connector
 1 x CPU fan header
 1 x CPU fan/water cooling pump header
 3 x system fan headers
 1 x system fan/water cooling pump header
 3 x addressable RGB Gen2 LED strip headers
 1 x RGB LED strip header
 3 x M.2 Socket 3 connectors
 4 x SATA 6Gb/s connectors
 1 x front panel header
 1 x front panel audio header
 1 x USB Type-C
®
header, with USB 3.2 Gen 1 support
 1 x USB 3.2 Gen 1 header
 2 x USB 2.0/1.1 headers
 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0/
GC-TPM2.0 SPI V2 module only)
 1 x reset button j
 1 x reset jumper
 1 x Clear CMOS jumper
Back Panel
Connectors
 1 x DisplayPort
(Note)
 1 x HDMI port
(Note)
 1 x Q-Flash Plus button
 4 x USB 2.0/1.1 ports
 1 x PS/2 keyboard/mouse port
 2 x USB 3.2 Gen 2 Type-A ports (red)
 1 x USB Type-C
®
port, with USB 3.2 Gen 1 support
 1 x RJ-45 port
 2 x USB 3.2 Gen 1 ports
 2 x antenna connectors (2T2R)
 3 x audio jacks
I/O Controller  iTE
®
I/O Controller Chip
Hardware
Monitor
 Voltage detection
 Temperature detection
 Fan speed detection
 Water cooling ow rate detection
 Fan fail warning
 Fan speed control
* Whether the fan (pump) speed control function is supported will depend on the fan
(pump) you install.
(Note) Actual support may vary by CPU.
j Only for B850 EAGLE WIFI6E.
