Gigabyte GA-8I915PC Duo User Manual

GA-8I915PC Duo Motherboard - 72 -
English
Manual setting:
If the device picture shows different from what you
set, please press "Manual Selection" to set.
If you set wrong with the connectors, the warning
message will come out as right picture.
UAJ Introduction
UAJ (Universal Audio Jack) has a very smart feature: It will switch signal automatically when user plugs his
audio device to the wrong jack (Line-in/ Line-out). That means users do not need to worry the audio device
should be plug in Line-in or Line-out jack, the device will work perfectly after UAJ is activated.
You can click "UAJ Automatic" button to enable UAJ
function.
Enable UAJ function:

Gigabyte GA-8I915PC Duo Specifications

General

Form Factor	ATX
CPU Socket	LGA 775
Chipset	Intel 915P
Memory Type	DDR
Memory Slots	4
Maximum Memory	4 GB
USB Ports	8 x USB 2.0
Expansion Slots	1 x PCI, 3 x PCI
LAN	Realtek RTL8110S
Audio	Realtek ALC880 8-Channel High Definition Audio CODEC
