Page #8 background imageLoading...
Page #8 background image
Expansion Slots Integrated in the CPU (PCIEX16/PCIEX8):
3rd Generation AMD Ryzen
processors:
- 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16 (PCIEX16)
- 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x8 (PCIEX8)
2nd Generation AMD Ryzen
processors:
- 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x16 (PCIEX16)
- 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x8 (PCIEX8)
* For optimum performance, if only one PCI Express graphics card is to be installed,
be sure to install it in the PCIEX16 slot.
* The PCIEX8 slot shares bandwidth with the PCIEX16 slot. When using the 3rd
Generation AMD Ryzen
processors/2nd Generation AMD Ryzen
processors, the
PCIEX16 slot operates at up to x8 mode.
2nd Generation AMD Ryzen
with Radeon
Vega Graphics processors/AMD
Ryzen
with Radeon
Vega Graphics processors:
- 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x8 (PCIEX16)
Integrated in the Chipset (PCIEX4/PCIEX1):
- 1 x PCI Express x16 slot, supporting PCIe 4.0
(Note 2)
/3.0 and running at x4
(PCIEX4)
- 2 x PCI Express x1 slots, supporting PCIe 4.0
(Note 2)
/3.0
Multi-Graphics
Technology
(Note 3)
Support for NVIDIA
®
Quad-GPU SLI
and 2-Way NVIDIA
®
SLI
technologies
Support for AMD Quad-GPU CrossFire
and 2-Way AMD CrossFire
technologies
Storage Interface Integrated in the CPU (M2A_SOCKET):
3rd Generation AMD Ryzen
processors:
- 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and
PCIe 4.0 x4/x2 SSD support)
2nd Generation AMD Ryzen
processors/2nd Generation AMD Ryzen
with
Radeon
Vega Graphics processors/AMD Ryzen
with Radeon
Vega Graphics
processors:
- 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and
PCIe 3.0 x4/x2 SSD support)
Integrated in the Chipset (M2B_SOCKET):
- 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and
PCIe 4.0
(Note 2)
/3.0 x4/x2 SSD support)
- 6 x SATA 6Gb/s connectors
- Support for RAID 0, RAID 1, and RAID 10
USB Integrated in the CPU:
- 3 x USB 3.2 Gen 1 ports on the back panel
- 1 x USB 3.2 Gen 2
(Note 2)
/Gen 1
Type-A port (red) on the back panel
Chipset:
- 1 x USB Type-C
port with USB 3.2 Gen 2
support, available through the
internal USB header
- 1 x USB Type-C
port on the back panel, with USB 3.2 Gen 2
support
- 1 x USB 3.2 Gen 2
Type-A port (red) on the back panel
- 4 x USB 3.2 Gen 1 ports available through the internal USB headers
Chipset+USB 2.0 Hubs:
- 8 x USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through
the internal USB headers)
(Note 2) For 3rd Generation AMD Ryzen
processors only.
(Note 3) For 3rd Generation AMD Ryzen
processors/2nd Generation AMD Ryzen
processors only.
- 8 -

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Gigabyte X570 AORUS PRO WIFI and is the answer not in the manual?

Gigabyte X570 AORUS PRO WIFI Specifications

General IconGeneral
Audio chipRealtek ALC1220-VB
Component forPC
Motherboard chipsetAMD X570
PC health monitoringFAN, Temperature, Voltage
Audio output channels7.1 channels
Motherboard form factorATX
Motherboard chipset familyAMD
Windows operating systems supportedWindows 10 Education x64, Windows 10 Enterprise x64, Windows 10 Home x64, Windows 10 Pro x64, Windows 10 x64
Processor socketSocket AM4
Compatible processor seriesAMD Ryzen 3 2nd Gen, AMD Ryzen 3 3rd Gen, AMD Ryzen 5 2nd Gen, AMD Ryzen 5 3rd Gen, AMD Ryzen 7 2nd Gen, AMD Ryzen 7 3rd Gen, AMD Ryzen 9 3rd Gen
Maximum number of SMP processors1
Non-ECCYes
Memory channelsDual-channel
Memory slots typeDIMM
Number of memory slots4
Supported memory typesDDR4-SDRAM
Maximum internal memory128 GB
Supported memory clock speeds2133, 2400, 2667, 2933, 3200, 3333, 3400, 3466, 3600, 3733, 3800, 3866, 4000, 4133, 4266, 4300, 4400 MHz
Cables includedSATA
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Bluetooth version5.0
Ethernet interface typeGigabit Ethernet
BIOS typeUEFI AMI
BIOS memory size128 Mbit
System Management BIOS (SMBIOS) version2.7
WiFi-AP antenna jack2
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity3
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity0
Number of SATA III connectors6
RAID levels0, 1, 10
Supported storage drive interfacesSATA III
Maximum resolution4096 x 2160 pixels
Parallel processing technology support2-Way CrossFireX, 2-Way SLI, Quad-GPU CrossFireX, Quad-GPU SLI
Weight and Dimensions IconWeight and Dimensions
Depth244 mm
Width305 mm
