MDE-5422B Latitude™ Owner’s Manual · March 2021 Page 5-7
Dispenser Start-up Latitude Operation
View Sale Totalizer
To view the Sale Totalizer, proceed as follows:
1 Ensure that the nozzles for that side are in the boot.
2 Press TOT to see the TOTALIZER string on the 16 X 2 Liquid Crystal Display (LCD) display
[see
Figure 5-11 (i)].
3 Press Sale to see the sale totalizer. By default TOTAILZER MON is displayed 
[see Figure 5-11 (ii)].
4 Press 1 to see the cumulative sale totalizer of Nozzle 1 Side 1 [see Figure 5-11 (iii)].
5 Press 1 again to see the shift-wise sale totalizer of Nozzle 1 Side 1 [see Figure 5-11 (iv)].
6 Repeat step 5 to see the cumulative and shift-wise sale totalizer of Nozzle 1 for Sides 2, 3, and
4 [see Figure 5-11 (v), (vii)].
7 Press 2 to see the sale totalizer of Nozzle 2 Side 1.
8 Press 2 again to see the shift-wise sale totalizer of Nozzle 2 Side 1.
9 Repeat step 8 to see the cumulative and shift-wise sale totalizer of Nozzle 2 for Sides 2, 3, and
4.
10 Repeat steps 5 and 8 for the remaining nozzles and press the corresponding key to view the
sale totalizer.
11 To exit the Totalizer menu, press F1.
12 To exit the Keypad menu, press F2. When F2 is pressed, the keypad displays the string
“READY”. To access other parameters, the user must enter the password again.
