Page 5-14 MDE-5422B Latitude™ Owner’s Manual · March 2021
Latitude Operation Setting Parameters
Figure 5-18: PPU CHANGE SET Mode
9 Press the F1 key to enter the PPU CHANGE menu. Repeat steps 4 on page 5-13 to 8 on 
page 5-13 to enter the prices for other nozzles or grades.
10 Upon completing any menu editing process, press F2 to reboot the pump. The pump returns to
the IDLE state after the reboot.
Command Code Mode
Level 1 Commands
Level 1 commands are most commonly performed on the site by the station owner/operator. The
programming level is accessed as shown in the following example.
Keypad: F1 > 2 - Signal programming mode to the dispenser
.
Sale
8 8 8 8
Volume
PPU
Keypad: XXXX - Security code for Level 1.
Sale
- - - -
Volume
PPU
Keypad: ENTER
Sale
0 0 0 0
Volume
PPU
