Gillette SPS-100 User Manual

PAGE 27
DC
SIGNAL − 12VDC
RUN GROUND WIRE
DC
ASCO 300
CONTROLLER
TB−14
TB−15
TB−16
ASCO−300 SERIES TRANSFER SWITCH
GND
GND
GND
OPTIONAL EQUIPMENT
DC
AC
ADD JUMPER
*REQUIRED!
JUMPER
DETAIL
DYNAGEN VIGALANTE SERIES TRANSFER SWITCH
GND
DC
ONLY THREE 14GA
12VDC
CONTROL LEADS WIRED THIS WAY
REQUIRED IF
GND
DYNAGEN VIGALANTE SERIES TRANSFER SWITCH
X
CONNECT TO DRY
CONTACT START/STOP
HIGH TEMPERATURE
DRY START/STOP CONTACTS
FROM OTHER EQUIPMENT
NEUTRAL
ENCLOSURE
GROUND
(MECHANICAL
GROUND)
LOAD SIDE
120/ 240 VAC
AND NEUTRAL
CONNECT TO
TRANSFER SW
GROUND
STAKE
FOR
CONTROLLER
SPH−&−SPS−EE−120/240VAC INTERCONNECT DETAIL
DC
GND
2−WIRE−DRY−CONTACT−START−STOP
GND
GND
GND
ASCO−165 SERIES TRANSFER SWITCH
ASCO 165
OVER CRANK
LOW OIL NOT IN STANDBY LOW BATTERY UNDER SPEED / FAIL
ENGINE RUNNING
OVER SPEED
ENGINE MONITOR
OFF / RESET
TEST
STANDBY
MODE SELECTOR
by GILLETTE GENERATORS, Inc.
SENTRY-PRO
DC
COMMERCIAL
CONNECT TO
POWER L1 AND
START SIGNAL
