3-10
Installation 3
Upgrading to Dual-syringe Model
Upgrading to Dual-syringe Model
The single syringe 402 can be upgraded to improve
the versatility of the system.
To upgrade to the Dual-syringe 402, you must
install a Tee-junction module (kit reference F4015010)
at the right-hand-side of the 402. You must first
install the syringe module (includes motor etc.) and
then fit the Tee-junction.
Before installing the module: make sure that the ON/
OFF switch is in the OFF position, remove the power
cord, and disconnect any hydraulic connections
from the 402.
