eNUSER’S MANUAL TC15
28
1. Press the key to have an access to the parameter.
2. Use the NUMERICAL KEYBOARDS to select the desired mode.
3. Press the key
to confirm or press the Key to return to
UF-4
8.5 ACCUMULATION | UF-5
1. Press the Key to access to the parameter.
2. Press the Numerical keyboards to select the desired mode.
3. Press the key
to confirm.
4. Press the key
to return to
UF-5
CONDITIONS OF ACCUMULATION
ACCU AB
A
0
stability required
1
stability NO required
B
0
The weight has to turn to 0 to accept the following accumulation
1
The weight NO has not to turn to 0 to accept the following accumulation
2
To eliminate TARE to accept the following accumulation
In working mode press the
for accumulation.
Press to watch the cumulative total
Press hold down 3 seconds to delete the record of accumulations.
8.7 CONFIGURATION OF THE SPEED OF THE CONVERTER|UF-7
1. Press the Key to access the parameter.
2. Press the Numerical keyboards to choose the desired mode:
Speed 0
Slow speed 7,5 Hz (factory default)
Speed 0
Standard speed 15 Hz
Speed 0
Fast speed 30 Hz
3. Press the Key
to confirm or press to go back to menu
UF7
8.8 BLIND|UF-8
ZP 0
off
ZP 1
one division not shown to zero (factory default)
ZP 2
two division not shown to zero
ZP 3
three division not shown to zero
ZP 4
four division not shown to zero
ZP 5
five division not shown to zero
1. Press the
to access the parameter.
2. Press the Numerical keyboard to introducier the desired value.
3. Press to confirm or press to go back to menu UF-8
