2.8. REPLACEMENT SPARE PARTS LIST
Firebricks
21 @ 230mm x 115mm x 38mm
4 @ 175mm x 115mm x 38mm
Brick Retainer
Steel 655mm x 445mm
Upper Baffle Plate
Steel 400mm x 160mm x 5mm
Lower Baffle Plate
Steel 500mm x 300mm x 12mm
Front Baffle Plate (with hooks)
Steel 670mm x 160mm x 12mm
Ash Plate
Steel 500mm x 75mm x 50mm
Door Seal
1610mm x 13mm round braided ceramic rope
Glass Seal
1360mm x 8mm x 3mm flat adhesive back
Door Glass
476mm x 200mm x 5mm pyro ceramic
