Global Caché GC-100 - Page 35

www.globalcache.com
6 ft. Cable
GC-CXG
Converter
GC-IRE
Not Used
Ground
Emitter Output
Ground Power
IR Output
 Converts voltage levels
 Optically isolates
IR Receiver
Remote
Xantech
SpeakerCraft
Niles
GC-CXG
Receiver Port
Emitter Ports
Power
Supply
IR input received by Software can
now trigger any system event
Sends digitized IR signals over the
network to control software
PC/Computing Device
Controller
IP Network
 New IR commands
 New Serial commands
 New relay commands
 Other system commands
Insteon, Z-Wave, ZigBee,
etc.
GC-100-12 Network Adapter
Serial Relay IR or Sensor
PWR
LAN
GC-CXG
GC-IRE
RS232
GC-IRE
 Digitizes IR
Signals
GC-IRE
IR Distribution
Block
IR to Digital Input Events (cont.)
GC-CGX Converter Cable
