ITEM DESCRIPTION QTY
1 1.2M REFLECTOR 1
2 YOKE ASSEMBLY 1
3 ELEVATION ROD 1
4 MOUNT HARDWARE KIT 1
5 BACKFRAME ASSEMBLY 1
6 FEED SUPPORT ARM ASSEMBLY 1
7 BRACKET, HW XPC 1
8 BOOM SUPPORT PLATE 2
9 ELEVATION SCALE PLATE 1
10 SUPPORT BRACKET ASSEMBLY 1
11 FEED SUPPORT HARDWARE KIT 1
12 SIDE STRUT 2
13 SFL XPC HORN/OMT FILTER
ASSY, LOW PROF
1
14 FEED HARDWARE BAG 1
15 REFLECTOR HARDWARE KIT 1
ITEM DESCRIPTION QTY
4-1 BOLT - M10 X 35 4
4-2 SET SCREW - M8 X 30 1
4-3 NUT - M12 2
4-4 NUT - HEX M8 X 1.25 1
4-5 WASHER, FLAT - M10 4
4-6 SPRING WASHER - M10 4
4-7 WASHER, LOCK - M8 1
4-8 WASHER, FLAT - M8 2
ITEM DESCRIPTION QTY
11-1 SET SCREW - M8 X 30 14
11-2 CAPSCREW - M8 X 25 1
11-3 WASHER, PLAIN - M8 1
11-4 WASHER, LOCK - M8 15
11-5 WASHER, FLAT - M8 14
11-6 ‘U’ TYPE DRIVE SCREW 4
1.0 PARTS LIST
ITEM DESCRIPTION QTY
15-1 COACH BOLT (M8 X 70) 4
15-2 SET SCREW (M6 X 25) 4
15-3 NUT, HEX (M8 X 1.25) STL 4
15-4 NUT, (M6) 2
15-5 WASHER, LOCK, (M8) 4
15-6 SPRING WASHER, (M6) 4
15-7 FLAT WASHER, (M8) 4
15-8 PLAIN WASHER (M6) 6
ITEM DESCRIPTION QTY
14-1 SCREW, HEX HD CAP M6 X 1.0 X
20MM
2
14-2 WASHER, LOCK, M6 1
2
