Global Surgical SMR MAXI Standard User Manual

Section 3 Product Information
3-3
Table 3-1 Specications
3.3. Specications
ALL DIMENSIONS
ARE IN INCHES.
STAINLESS STEEL LAMINATE ALUMINUM COMPOSITE
STANDARD
STANDARD
TALL
DELUXE
DELUXE
TALL
MINI STANDARD
STANDARD
TALL
DELUXE
DELUXE
TALL
OVERALL HEIGHT HIGH
BACK, W/CASTERS
(LOW BACK)
49
(N/A)
60.5
(N/A)
49
(N/A)
60.5
(N/A)
49
(N/A)
49.5
(39.25)
60.5
(50.25)
49.5
(39.25)
60.5
(50.25)
COUNTER TOP
HEIGHT W/CASTERS
33.5 44.75 33..5 44.75 33.5 33.5 44.75 33..5 44.75
WIDTH
24.75 24.75 34.5 34.5 24.75 29 29 38.25 38.25
CORDED OTOSCOPE ADDS 3.25 CORDED OTOSCOPE ADDS 2.25
DEPTH
17.25 17.25 17.25 17.25 17.25 19 19 19 19
GLOVE OR TISSUE DISPENSER ADDS 3 INCHES
QTY DRAWER:
3.5 H X 9.25 W X 10 D
2 2 2 2 2 2 2 2 2
* CHANGES TO 1 DRAWER 3.5” x 12.25 W x 10D WHEN LED LIGHT SOURCE IS SELECTED
QTY DRAWER:
2 H X 20.25 W X 13.25 D
2 4 2 4 2 2 4 2 4
QTY DRAWER:
3.5 H X 20.25 W X 13.25 D
1 2 1 2 1 1 2 1 2
TRASH PORT N/A N/A OPTIONAL OPTIONAL N/A N/A N/A OPTIONAL OPTIONAL
DIRTY INSTRUMENT TRAY 0 0 1 1 0 0 0 1 1
GLASSWARE / COTTON
JAR INCLUDED:
S A163
A S286
S A3312
S A163
A S286
S A3312
S A163
A S286
S A177
S A3312
S A163
A S286
S A177
S A3312
NONE
S A163
A S286
S A3312
S A163
A S286
S A3312
S A163
A S286
S A177
S A3312
S A163
A S286
S A177
S A3312
MAXIMUM VACUUM 4.4 CFM (125 L/MIN) @ OPEN FLOW; 25 IN Hg (635 mm Hg)
MAXIMUM PRESSURE FACTORY SETTING 20 PSI, PUMP CAPABLE OF 60 PSI
ELECTRICAL 110-120VAC, 60 HZ, 13 AMPS
SHIPPING WEIGHT
200 LBS 250 LBS 250 LBS 300 LBS 200 LBS 250 LBS 300 LBS 300 LBS 350 LBS
MAY VARY BY OPTIONAL COMPONENTS SELECTED
STORAGE, OPERATING & CERTIFICATION INFORMATION
CONDITION OPERATING ENVIRONMENT STORAGE ENVIRONMENT WATER RESISTANCE
TEMPERATURE: 15°C TO 40°C (59°F TO 104°F) -20°C TO 50°C (-4°F TO 120°F)
NOT PROTECTED
EQUIPMENT IP01
RELATIVE HUMDITY: 15% RH TO 75% RH 30% RH TO 95% RH
AIR PRESSURE: 70-106 kPa 70-106 kPa
CERTIFICATIONS:
IEC 60601-1: 2014 ED 3.1 IEC 60601-1-2: 2014 ED 4
UL STD 60601-1 MEDICAL EQUIP SEE APPENDIX A-3 FOR ADDITIONAL LISTINGS
TYPE B EQUIPMENT
CLASS 1 EQUIPMENT
TYPE B APPLIED PARTS:
SUCTION TUBING, PRESSURE TUBING
AND CORDLESS OTOSCOPES
TYPE BF APPLIED PARTS:
CORDED OTOSCOPE AND
LED LIGHT SOURCE
