Section 5 Care and Maintenance
5-9
USE HOSPI
T
A
L
GRADE POWER CORD
T2A L250
7. On back of unit, remove fuse by turning fuse cover counter-clockwise and pulling out fuse. Replace fuse
with 2 AMP (1/4” x 1 ¼”) time delay 250V rated fuse.
8. Insert back into fuse housing and twist clockwise until it clicks into position.
9. Re-connect the power cord.
10. Push light source back in place and install screws.
11. Put drawers back in place in the same position from which they were removed.
Fuse Compartment
Power Cord Inlet
Figure 5-5. S 740200LED Light Source Back Panel
