DIA No. Part Number Description NO Req'd
1 VF82010 CLEAR COVER, RECOVERY TANK 1
2 VF82930 DECAL, BATTERY WARNING 1
3 VF82009 ELBOW ADAPTER, FLOAT 1
4 VV13607 WASHER, LOCK, M6 13
5 VF13533 WASHER, PLAIN, M6 X M16 X 2 7
6 VF14233 SCREW, M6 X 20 4
7 VF81504 FLOAT 1
8 VF82002 RECOVERY TANK 1
9 VF13528 WASHER, TOOTH, LOCK, M6 2
10 VF13495 SCREW, M6 X 16 2
11 VF82028 CABLE 1
12 VF81509 PLUG, EXPANSION 1
13 VF81510-9 STRAP, DRAIN HOSE 1
14 VF81510-2 SLEEVE, DRAIN HOSE 1
15 VF81510A DRAIN HOSE ASSEMBLY 1
16 VF82115 DECAL, BATTERY INSTALLATION 1
17 VF82318 HOOK, CABLE 4
18 VF82326 MESH COVER, CABLE 1
19 VV10113 CLAMP, 2" 2
20 VF14225A SCREW, M6 X 40 4
21 VF81723 CONNECTOR 1
22 VF82331 ON BOARD CHARGER, 9AMP, 24V 1
23 VF82332A KIT,CHARGER REPLACEMENT 1
24 VV13601 WASHER, LOCK, M5 4
25 VF13532 WASHER, PLAIN, M5 X M11 X 2 4
26 VV20501 SCREW, M5 X 14 4
27 VF82331A KIT, ON BOARD CHARGER 1
28 VF82332 CLAMP, CHARGER 2
29 VF82320 CLAMP, CABLE 2
30 VF13502 NUT, LOCK, M6 3
31 VF82310 STUD 3
32 ZD53000 MOTOR, VACUUM, 2 STAGE, 24VDC 1
33 VF13521 NUT, M6 3
34 VF81503 SEAT 1
35 VF14200 SCREW, M6 X 16 9
36 GT13032 WASHER, PLAIN, M6 X M16 X 1.5 9
37 VF82011 HINGE, RECOVERY TANK 1
38 VF82929 LOGO 1
39 VA13477 SCREW, SELF-TAPPING, ST, M4 X 16 4
40 VV13664 WASHER, PLAIN, M4 X M12 X 1 4
41 VF82010A RUBBER HINGE 1
42 VF82010B GASKET 1
43 VF82010X KIT, LID 1
MODEL 261123 & 261124 - RECOVERY TANK ASSEMBLY
14
