DIA No. Part Number Description NO Req'd
1 ZD45000 BRUSH MOTOR, 24VDC, .75HP 1
2 ZD45407 KEY, 6.35 X 25 1
3 VF13545 SCREW, SELF-TAPPING,ST, M5 X 10 4
4 VV13601 WASHER, LOCK, M5 4
5 VF83131 CLAMP, BRUSH PLATE 1
6 VF83132 SPRING 1
7 VF83130 PLATE, DRIVE 1
8 VF82058 WASHER 1
9 VV20298 WASHER, LOCK, 5/16" 1
10 VF14241 SCREW, 5/16"-1" 1
11 VF82057 PAD DRIVER, 19" 1
12 VF14225A SCREW, M6 X 40 3
13 VF83133 STUD 3
14 VF13502 NUT, LOCK, M6 3
15 VF83118 SPACER 1
16 VF99003A BIG MOUTH 1
17 VA13484 SCREW, SELF-TAPPING,ST, M4 X 12 3
18 MF-VF002-4A SCREW, SELF-TAPPING, 1/4"-1" 3
19 VF83130A PLATE, DRIVE, ASSY 1
20 VF83134 STOP, DRIVE RELEASE 1
21 VF14242 SCREW, 3/8"-1 4
22 VV13620 WASHER, LOCK, 3/8" 4
23 VF13537 WASHER, PLAIN, M10 X M26 X 2 4
24 VF82148 CLAMP, 16mm 1
25 VF82077 TUBING, 55mm 1
MODEL 261123 & 261124 - BRUSH PAD ASSEMBLY
27
