Keep the instructions for future reference.
NF EN 14619:2019 - CLASS A : 100 kg MAX
READ THE INSTRUCTIONS PROVIDED BY THE MANUFACTURER BEFORE USING.
1 - SAFE USE OF THE ELECTRIC SCOOTER
As stated by EN60335-1, this appliance can be used by children aged from 8 years and
above, persons with reduced physical, sensory or mental capabilities or lack of experience
and knowledge, if they have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved. Children shall not play
with the appliance. Cleaning and user maintenance shall not be made by children without
supervision.
Warning. Never use the product close to a water source. Stop using the product when
damaged.
2 - TECHNICAL SPECIFICATION
Material
Steel, aluminium, polypropylene
Unfolded Dimension
97 x 46 x 103cm
Folded Dimension
86.5 x 46 x 36cm
Weight
8 kg
User height /
Minimum - maximum weight
1.55m - 2.0m /
50 - 100kg
Maximum Speed
20 km/h
Maximum range per charge
15 km*
Operating temperature
0°C - 40°C
Motor Power
250 W
Front Wheel Size
8” (203mm)
Rear Wheel Size
8” (203mm)
Battery Capacity (Ah)
2.6Ah
Battery voltage
36 V (End-of-discharge voltage : 27.5 V -
Upper limit of the charging voltage : 42 .5 V)
Charger
AC input 100-240v 50/60HZ
DC output 40V 0.8 A
Charging time
3-4 Hours
External LED light
4 hours working time supported by
1500mAH lithium battery; max. beam of
95m; USB charging.
Sealing around compartment
IPX4
*depending on the user’s weight.
Original instructions
3 - ASSEMBLY
UNFOLD THE SCOOTER
- Press the button on the side, then raise the t-bar until the folding mechanism is engaged;
make sure you hear a “click” sound.
- After unfolding the scooter, put the Folding Lever in an upward position before riding
to ensure that it doesn’t come into contact with your feet while riding.
- In case the side button gets jammed and can not be pressed, please lift the t-bar tube
the side button.
OK!
For folding only.
OK to ride!
4
ENGLISH
To Next Page
