270 Vehicle Care
Acadia with Halogen Lighting
The vehicle may not be equipped
with all of the fuses, relays, and
features shown.
Fuses Usage
A/C CLTCH Air Conditioning
Clutch
ABS MTR Antilock Brake
System (ABS)
Motor
AIRBAG Airbag System
AUX POWER Auxiliary Power
AUX
VAC PUMP
Auxiliary
Vacuum Pump
AWD All-Wheel-Drive
System
BATT 1 Battery 1
BATT 2 Battery 2
BATT 3 Battery 3
CIGAR
LIGHTER
Cigarette Lighter
ECM 1 Engine Control
Module 1
ECM/
FPM IGN
Engine Control
Module/Fuel Pump
Power Module
Ignition
EMISSION 1 Emission 1
