248 Vehicle Care
Fuses Usage
F27 Antilock brake VAL
F28 LD trailer
F29 Rear window
defogger
F30 Mirror defroster
F31 –
F32 Variable functions
F33 –
F34 Horn
F35 Vacuum pump
F36 Right high-beam
headlamp
F37 Left high-beam
headlamp
F38 Automatic headlamp
leveling
F39 Fog lamps
F40 –
F41 Transmission range
control module
F42 Motorized headlamp
F43 Fuel pump
Fuses Usage
F44 Interior rearview
mirror
F45 Canister vent
solenoid
F46 Driver side
Ventilated Seat
F47 Steering column lock
assembly
F48 Rear wiper
F49 –
F50 Heated steering
wheel
F51 Right headlamp
F52 Engine control
module/
Transmission control
F53 –
F54 Front wiper
F55 Front wiper speed/
Control
F56 –
F57 Left headlamp
Relays Usage
K01 Starter solenoid
K02 Air conditioning
control
K03 –
K04 Wiper control
K05 Starter Solenoid
K06 –/Fuel
heater (diesel only)
K07 –
K08 –
K09 Wiper speed
K10 –
K11 –
K12 High-beam
headlamps
K13 Headlamps/Daytime
running lamps
K14 Run/Crank
K15 Rear window
defogger
*K16 Horn
