3
I. MAIN SPECIFICATIONS
II. SAFET Y INSTRUCTION
WARNING: THIS IS A VERY DANGEROUS MACHINE! FAILURE TO FOLLOW THE
SAFETY RULES MAY RE SULT IN SERIOUS PERSONAL INJURY
As with all machinery there are certain hazards involved with operation and use of the
machine. Using the machine with respect and caution will considerably lessen the
possibility of personal injury. However, if normal safety precautions are overlooked or
ignored, personal injury to th e operator may result.
This machine was designed and constructed for roll forming metal plate and some
similar material. We strongly recommend that this machine SHOULD NOT be modified
and/or used f or any application other than for wh ich it was designed. If you have any
questions about its application, do not use the machine until you contact us.
Read all instructions before using this very dangerous machine!
1. MACHINERY GENERAL SAFETY WARNINGS
1) Misuse of this machine can cause se rious injury. For safety, machine must be set up,
used and serviced properly. Read, understand and follow instructions in the operator’s
and parts manual which was shipped with your machine.
2) Wear proper apparel. No loose clothing o r jewelry which can get ca ught in moving
MODEL PBR-0412E PBR-04316E PBR-0425E PBR-0510E
PBR-0610E
Max rolling width 51” 51” 51” 61” 81”
Max rolling thickness 12GA 3/16” ¼” 10GA 10GA
Rolling diameter 3-1/2” 4-3/4” 5-7/8” 4-3/4” 5”
Rotate speed 22rpm 16.5rpm 15rpm 16.5rpm 16.5rpm
Bending roll up/down motor motor motor motor motor
Main motor 2HP 3HP 4HP 3HP 4HP
