8
Apollo Lasher
Figure 6
Figure 7
Figure 8
2. Verify that the adjustable
tension roller is in the correct
position for the type of
lashing. The roller should be
in the lower-most position
for normal lashing wire
tension, including lashing
broadband coaxial cables.
The roller should be in the
upper - most position for
higher lashing wire tension.
3. Depress the reel brake into
cutout on rear flange.
Unscrew and remove the
wire reel cover and slide the
lashing wire coil over the hub
and onto the reel making
sure that it spools out to the
rear of the lasher as shown
by arrow.
4. Install the wire reel cover
and thread completely
onto the reel until snug
against the wire coil. It is
important to ensure that
the reel cover is tight
against the wire coil to
prevent the lashing wire
from “snagging” on itself.
