REF # PART # DESCRIPTION
1 42-810-01 CRANK CASE
2 42-810-02 GASKET, CRANK CASE
3 42-810-03 COVER, CRANK CASE
8 & 9 42-810-04 OIL GAUGE & O-RING
6 42-810-05 PLUG, FUEL DRAIN
7 42-810-06 O-RING
10 42-810-07 SCREW
18 42-810-09 PLUNGER COVER
4 42-810-10 OIL CAP
5 42-810-11 O-RING
13 42-810-12 PIN
14 42-810-13 BED, CRANK CASE
15 42-810-14 BOLT
16 42-810-15 WASHER, SPRING
17 42-810-16 WASHER
21 42-810-21 CRANK SHAFT
22 42-810-22 CONNECTING ROD ASS’Y
25 42-810-25 PLUNGER PIN
26 42-810-26 CERAMIC PLUNGER ASS’Y
27 42-810-27 BEARING
28 42-810-28 OIL SEAL, CRANK SHAFT
29A 42-810-29A COVER, OIL SEAL – A
29B 42-810-29B COVER, OIL SEAL – B
30 42-810-30 SCREW
31 42-810-31 KEY
32 42-810-32 PULLEY
33 42-810-33 BOLT
34 42-810-34 WASHER, SPRING
35 42-810-35 WASHER
12 42-810-41
OIL SEAL, PLUNGER
Page 7
