GOAL ZERO Sherpa 100AC User Manual

54
Turn on/off the display.
Turn wireless charging on/off. Button light is
white when wireless charging is turned on and
turns green when connection with device is made
and charging begins. Place your smartphone on
top of the device over the black charging square
to begin charging.
Turn on/off the USB-A ports.
Turn on/off AC port.
Slide switch on the back of the Sherpa to change
your USB-C ports between Input/Auto/Output.
Input means you are inputting power to your
Sherpa. Output means you are outputting power
from your Sherpa.
CHARGE ME NOW: Plug in and charge up before first use.
FROM USB: Plug into a USB-C port using the included USB-C cable and one
of the USB-C Power Delivery (PD) ports on the Sherpa. You can also purchase
one of our 65W USB-C chargers for a 2 hour recharge.
FROM SOLAR: Pair the Sherpa with a Nomad or Boulder Solar Panel and
charge up from the sun using the 8mm input. For the best solar charging
performance, we recommend the Goal Zero Nomad 50 Solar Panel.
FROM AC or 12V: Utilize the 8mm port on the Sherpa 100AC with our
accessory 12V Car Charging Cable or the Sherpa Power Supply (sold
separately). Accessories are available from GoalZero.com. Give our customer
solutions center a call for help at 888-794-6250.
HOW IT WORKS
USING THE SHERPA
We recommend using a USB-C to USB-C cable when recharging enabled
laptops. Since USB-C PD ports are bidirectional, meaning they can
function as an input to charge the Sherpa or an output to charge other
devices, plugging in a laptop may cause the Sherpa to try charging from
the laptop’s internal battery, rather than charging the laptop. To fix this,
slide the selector switch on the back of the Sherpa to “OUTPUT”
The Sherpa can be charged and recharge other devices simultaneously.
Keep in mind that if you are outputting more power than you are
inputting you will drain the Sherpa battery and the device will turn off.
Plug the Sherpa into a power source and make sure it is still powered on,
then plug the phone/laptop/tablet or other device into the Sherpa.
TIPS for LAPTOP CHARGING via USB-C PD:
PASSTHROUGH CHARGING:
BUTTONS:
CHARGE BEFORE USE

GOAL ZERO Sherpa 100AC Specifications

General

Cell Type	Li-ion NMC
USB-A Output	5V, up to 2.4A (12W max)
Wireless Charging Pad	10W Max
Input USB-C	5-20V, up to 3A (60W max)
Cycle Life	500 cycles to 80% capacity
Operating Temperature	32-104 F (0-40 C)
Battery Capacity	94.7 Wh (14.8 V, 6400 mAh)
AC Output	100W (Continuous), 150W (Surge)
USB-C PD Output	60W Max
AC Output (Surge)	150W
Input Options	USB-C PD
Weight	2.0 lbs (0.91 kg)
Charging Time	Approximately 2.5 hours from USB-C PD
